Skid steer loader augers
  • Digga North America - Skid steer loader attachments.

Augers for Skid Steer Loaders 2.5-3.8t

Digga's drilling augers for skid steer loaders are the ultimate in performance, quality and cost effectiveness. Over 30 years of design and development has produced the highest quality range of auger drives on the market today. Completely manufactured and assembled by Digga, using only the highest grade materials and strictest quality control.

Fitted with Digga / Eaton bell motors and input housing,he innovative design allows the gearbox to go down the hole to maximise drilling depth without extentions, eliminating downtime and minimises maintenance, optimizing your returns.

Digga drilling augers are backed by industry leading warranty and local factory support.

Features

  • Compact Digga manufactured gearbox
  • Digga designed Eaton motor
  • 2 Piece shaft design ensures maximum side load ratings without increasing load on bearings
  • Lifetime shaft pull out warranty
  • 5 year gearbox and 3 year motor warranty
  • Over 30 years design and manufacturing experience
Specs 3dSs 4dSs 4DDS
Torque (ft-lbs
@ 3000 Psi
2,829 3,275 3,583
Max Torque ft-lbs
@ 3500 Psi
3,300 3,821 4,180
Recommended Flow (gpm) 10-30 10-30 10-36
Motor Type Eaton Eaton Eaton
Max pressure -
do not exceed
3500 psi @ 16 gpm 3500 psi
@ 27 gpm
Max flow -
do not exceed
30 gpm @ 1800 psi 42 gpm
@ 3100 psi
Max horse power 34 34 55
Pressure relief valve N/a n/a INCLUDED
standard output shaft 2" Hex 2" Hex 2" Hex

Recommended auger A4 / rC4 A4 / rC4 A4 / rC4
Max drilling diameter
(clay / shale)*
24" 24" 24"
Max drilling diameter
(earth)*
30" 30" 40"
Weight (lbs) 123 125 180
Overall length (in) 25.9" 25.9" 29"
Diameter (in) 9.4" 9.4" 9.4"
(*) Max/min drilling diameter (DIA) dependant on ground conditions. Guide is a recommendation only.
Digga North America - 4DDS Auger Drive Unit
